Top-Down Integration Testing:

The top-down integration testing approach is a gradual integration approach that puts the integration of modules in progress as per the software system architecture from the top to the bottom. Testing is initiated with the high-level modules and continues until the lower-level modules are covered. Then, integration is performed to ensure the entire system is up and running. In this approach, stubs and drivers are made use of to mimic the behavior of modules that have not been combined yet. Stubs offer a temporary stand-in for those specific modules called in the test, producing the same result every time. The approach, therefore, helps in the simulation of behavior prior to actual integration.

In top-down integration testing, one starts with the first sub-system of the application. This is the topmost module for testing, progressing downwards and integrating successively more subordinate modules or subunits. This process of hierarchical integration persists until out all the modules are integrated and verified.

Steps of Top-Down Integration Testing:

1. Start by testing the high-level modules first.

2. Proceed to the lower-level modules.

3. Perform integration to ensure the system works correctly.

Process:

Start at the Top-Level Unit: This means that the hardest module is tested first in an attempt to ensure either its failure or test failure.
Integrate with Sub-Level Units: The modules developed in the lower levels are then combined and checked in a sequential manner, according to the top-bottom integration test method.
Continue Hierarchical Integration: This process continues, and if the integrated module is dependent on it, the top-down integration process must confirm that the newly integrated module works correctly with the earlier integrated modules.
Handling Non-Ready Units:

If a lower-level module is not ready during the integration:

Use Stubs: In order to send messages to the other units in the application, developers build stubs which are actually pretend units which behave in a similar manner to the real unit.
Temporary Solution: These stubs enable the integration process to continue by indicating to the testing phases that other units are still being developed.

Replace with Real Units: After, the actual module is built, lighter-weight stub services are substituted for heavier-weight ones, and integration testing is carried out again to make certain that the new component interfaces correctly.

Advantages:

Incremental Testing: This approach allows for testing to take place incrementally between lower-level and higher-level components.
Parallel Development: It makes it easier to develop in parallel for different modules within a team.
Efficiency: Top-down integration testing can often be an efficient approach.

Top-Down Integrated Testing Methodology has below listed benefits:

Early Detection of Major Design Flaws:

The idea with starting from the top level modules by testing is that most critical design and architectural problems can be detected in the beginning of the test phase. This assists in tackling numerous constructive concerns before escalating to reduced echelons.

System-Level Perspective:

This implies that testing commences at the high level of the system hierarchy, and as a result, the general features and system flow are tested early. This is very useful in forming a complete appreciation on how well the system integration is achieving the intended objectives and whether key functionalities in the system are well functioning.

Facilitates Progressive Testing:

Top-down integration makes it possible for the integration and testing to be done in many steps whereby, actual modules are integrated at different stages. This makes it easier when conducting the V-model to detect the defects in every level of integration.

Simplifies Stubbing:

The approach makes it easier to create stubs because stubs are only needed for creating lower level modules. This is easier as compared to the formation of drivers as the latter is required when proceeding with a bottom-up approach.

Improved Test Case Design:

This is because, compared to other equivalent methods, test cases can be designed more effectively since the top-level modules outline the general operations and processes. This helps to guarantee that components of the application that are critical to the usage and functioning of the software are exhaustively tested right from the onset.

User Interface Focus:

It it the top-level modules require to include user interface, these might be possible to be tested also. This enables early check of user input and other aspects of usability, which are important for the adoption of the developed software.

Enhanced Documentation and Understanding:

The integration is based on a natural decomposition of the architecture that results in upper-half first-order reasoning, and it also aids in keeping good documentation as it is top-down based. This makes the handling of the integration process much easier as there is a clearer perspective of what is involved.

Prioritization of Critical Path Testing:

The critical paths and all the main functions or processes are initially run and tested. This prioritization helps in effectively validating the most essential aspects of the system early in the development phase and take appropriate measures to prevent development of issue that could cause major set back later on.

Efficient Handling of Changes:

In software development it helps to change or make enhancements in the top-level modules because lower-level modules are proven to still be under construction or integration. This lessens dependency on measures that will make drastic changes on the overall system.

Structured and Systematic Approach:

The planned, step-by-step approach is logical to implement from the top and work its way down. This progressive approach also helps to make sure that each level of the system has been rigorously tested before leaving the level to increase test coverage and confidence.

Disadvantages:

Stub Complexity: The usage of stubs, requiring the use of many stubs, may make the process of testing complex.
Inefficiency in Lower-Level Module Testing: Modules at the lower level may receive inadequate testing within this approach.
Incomplete Testing at Initial Stages: During the initial period of testing even the lower levels of modules are not fully tested since dummy modules are used for the actual modules. This can result in low level testing of those modules until higher stages are reached.
High Dependency on Stubs: Possibly more complex and difficult to maintain: Depending upon the design, the use of stubs may be required in cases where lower level modules are not yet being developed which is an overhead in itself. Developing and maintaining these stubs could be as time-consuming as writing actual essays, and it also entails more mistakes.
Delay in Identifying Issues in Lower-Level Modules: Because lower level modules are integrated and tested during a comparatively later stages of the process, problem and faults of these modules might be identified at relatively a later stage in the development process, and this can effectively slow down the entire process of development.
Resource Intensive: Top-down integration testing takes time and resources since actual stubs have to be established and it is necessary to check if the topmost system modules correctly interface with the established stub. However, since more tests are being run, this can also increase the testing overhead and time that is needed for the integration of systems.
Complex Debugging: Debugging and isolation of them is not so easy because some of them may be connected with interactions with the real top-level modules and stubs, therefore the exact place of the error appearance can be very hard to be detected.
Potential Overemphasis on Top-Level Functionality: The use of Parnas’ approach means that there is always a possibility of giving too much emphasis on the utility of the first order modules while possibly leaving behind a proper testing of the second order modules to some subsequent phases. This at times can lead to shift in the testing focus especially where the complicated designs are incorporated.
Integration Delays: Even if the use of stubs provides the higher level of integration, lower level modules might not be available on time and thus slow down the construction of the subsequent levels. The extent of dependency on module readiness, which in turn affects the overall project time line and planning.

Example Scenario:

Consider a software application with a hierarchy of modules:

Module A (Top-level)
Module B (Sub-level)
Module C (Sub-sub-level)

In top-down integration testing:

Start with Module A: Start testing the first major component which at the highest stage of the tree.
Integrate Module B: When you are done with testing Module A, proceed with testing after incorporating Module B into your creation.
Stub for Module C: If the Module C is not ready yet, write a faux-module that replaces the actual module and differs only in behavior. This stub enables one to check, in what way, Module A and Module B interact inasmuch as Module C is expected to act in a given manner.

here's a diagram to illustrate the top-down integration testing approach, including the use of stubs:

Top-Level Module (A): This is the topmost level through which testing starts hence serves as the supreme module.
Sub-Level Module (B): This is followed by reintegrating the top level module next to this one as shown in the following unit.
Sub-Sub-Level Module (C): if this module is not available a ‘dummy’ is used in order to give an imitation of the actual functionality of this product.

       Top-Level Module (A)
           |
           v
     Sub-Level Module (B)
           |
           v
Sub-Sub-Level Module (C) (Stub)

Here's the reference video for you to watch and better understand the topic:

Conclusion:

In general, top-down integration testing is applicable in integration testing, especially where the scenarios are correct. It makes incremental testing and parallel development of the components possible. However, it may require the use of many stubs and might not entirely test the lower-level modules.

This means that the top down integration testing is a proper technique to be used in the integration and testing of modules right from the top level. It also helps to make a system evolve in a step by step manner where the higher level components undergo complete testing before incorporating the lower level components. The reason why integration stubs are used on non-ready units, so that integration does not halt, allowing checks to take place regularly.
